wow check that beam wing :O
Great shots once again zgred!
- Login or Register
No account yet? Sign up
Team: Frank Williams (TP), Patrick Head (DE), Adam Parr (CEO), Sam Michael (TD), Alex Burns (COO), Toto Wolff (NED), Ed Wood (CD), Jon Tomlinson (CA)
Drivers: Rubens Barrichello (9), Nico Hülkenberg (10), Valeri Bottas (test)
It's your average shark-fin connecting to the rear-wing.raymondu999 wrote:is that an f-duct fin? It looks awfully small/thin if it is
Yes, it is. It has a slight triangular profile, with the bottom being wider that the top, which is ery thin. The slot in the rear wing can be seen in the second photo.raymondu999 wrote:is that an f-duct fin? It looks awfully small/thin if it is
Yeah the beam wing has a slot on the backside like the main beam of the rear wing.wesley123 wrote:wow check that beam wing :O
Great shots once again zgred!
I suspect it's hooked up to some sort of venting system, where the exhaust gases are fired straight out of the building =)volarchico wrote:From that shot it looks like the exhaust runs all the way down and back behind the diffuser completely. Must be an optical illusion.
Most likely!roost89 wrote:I suspect it's hooked up to some sort of venting system, where the exhaust gases are fired straight out of the building =)volarchico wrote:From that shot it looks like the exhaust runs all the way down and back behind the diffuser completely. Must be an optical illusion.
